12
SAFETY PRECAUTION:
HEED THE WARNING LABEL PLACED
ON THE OUTER LADDER RAILING
REGARDING THE USE OF THE WORK
PLATFORM AS A SPREADER
ATTACHMENT. (120KG MODEL ONLY)
DO NOT USE THE INNER SECTION
WHEN SEPARATED FROM THE
OUTER SECTIONS IN THE EXTENSION
LADDER POSITION.
10. Set out the two trestles and position a
compatible scaffolding plank on a set of
rungs at the required working height.
(See Figure F-9).
Figure F-9
Figure F-8
8. The stepladder is now set up for use
as a second trestle (See Figure F-8).
Once the hinge lock pins snap into
place, insert the work platform as a
spreader to brace the ladder.
(See Figure A-7)
Refer to page 15 for more information
on how to insert the Work Platform.
(120KG MODEL ONLY)
9. IMPORTANT
To Next Page
