Title Remain
TT 01/35 CH 25/38 0:49:20
Title Elapsed
TT 01/35 CH 25/38 1:26:16
OTHER FUNCTIONS
BASIC OPERATIONS
BASS/TREBLE EFFECT
TIME DISPLAY
ZOOM
WATCHING A MOVIE IN DIFFERENT
ANGLES
Pressing BASS/TREBLE button can adjust the level
of bass, treble and volume of the audio output.
1. Pressing BASS/TREBLE on the remote control or
unit repeatedly, “Bass”, “Treble” and “Vol” will
appear on the lower left corner of the screen
alternatively.
2. After choosing the desired mode, use the VOL UP
or VOL DN button to adjust the level of the effect.
- This function works for
ECHO: 00 +01 +02 ... +20
KEY: -7 -6 -5 ... 0 ... +5 +6 +7
:
1. KEY function works for
2. KEY button is used to adjust the key level back
to default level.
3. ECHO has no effect if no microphone plugged-in.
Pressing the DISPLAY button during normal playback
will allow the TV to display different time modes. The
following will appear on your TV screen in sequences
shown below:
“Title Elapsed” mode appears if DISPLAY button is
being pressed once. It shows the time of the current
title elapsed.
“Title Remain” mode appears after the “Title Elapsed”
mode as long as the DISPLAY button has been
pressed again. This mode shows the time remaining
in this title.
“Chapter Elapsed” mode follows the “Title Remain”
mode if DISPLAY button is being pressed again. It
shows the time of the chapter elapsed.
Next mode is “Chapter Remain”. It shows the time
remaining in this chapter.
Display mode will turn off if DISPLAY button is being
pressed in “Chapter Remain” mode.
1. This function is not available for Kodak picture CD
and MP3 disc.
2. For CDG and CD discs, the display sequence is
different from the above:
Single Elapsed Single Remain Total Elapsed
Total Remain OFF (It will not display on screen.)
This unit has six different zoom modes. Pressing the
ZOOM button on the remote control repeatedly will
display as shown below on your TV screen:
2X 3X 4X ½ X X 1/4X Normal Play
:
1. This function only works on DVD disc.
2. “2X” means the size of the playback screen is
enlarged (approximately) two times more than the
default. “½ X” means the size of the playback
screen is reduced to (approximately) half of the
original default.
3. The enlarged picture can be moved by the cursor
on the remote control. The position of the picture
will move and be shown on another display on the
TV screen.
Some DVD discs contain scenes which have been
shot simultaneously from a number of different
angles. Therefore, the same scenes can be viewed
from different angles by pressing ANGLE button
repeatedly. (The recorded angles differ from disc to
disc.)
1. This function only works on DVD disc.
2. If the DVD disc is recorded with only one angle,
this function will not be available.
NOTE
NOTE
NOTE:
NOTE
NOTE:
all discs or tape.
The ECHO button allows the user to adjust the ECHO
effect from the microphone. Pressing the ECHO
button on the remote control will display “ECHO” on
the lower left corner of the TV screen as shown below:
Pressing the KEY + / KEY - button on the remote
control will allow different ranges to be adjusted as
shown below:
all discs and cassette
tapes.
4. Key effect can be adjusted directly by pressing
KEY / KEY / KEY buttons on the remote
control or on the unit.
5. Echo effect can be adjusted directly by pressing
ECHO +/- buttons on the remote control or rotate
the ECHO control on the unit while using the
microphone.
1/3
ECHO/KEY
aa aa aa Aa
aa aa aa Aa aa Aa aa aa
N
UN Z
aa aa aa
aa
aa aa aa aa aa aa
Chapter Elapsed
TT 01/35 CH 25/38 0:02:21
Chapter Remain
TT 01/35 CH 25/38 0:01:38
Display Off
20
To Next Page
