— E7 —
Connecting to Line In Jack
Connect an external device by using an
appropriate cable (3.5mm audio cable not
included) as shown.
Note:
See page E18 to select and use the Line In
function.
Operation
Disco Lights
When the unit is turned on, the Light mode 1 is
automatically activated. The lights will light up
and will synchronize with sound when you speak
or sing into the microphone.
Press the LIGHTS button for Light mode 2
which will display the light show but will not
respond to the microphone.
Press the LIGHTS button again to turn off the
Lights.
To External Unit
AUDIO OUTPUT
/ HEADPHONE JACK
LINE IN
u
u
Press the button to easily set the machine
into pairing mode.
Note: See page E15 for Bluetooth operation
instructions.
Bluetooth Mode
To Next Page
