Rear Panel
N2200XXX:
The N2200XXX rear panel features ports and connectors.
Back Panel
Item Description
eSATA Port eSATA port for high-speed external storage expansion.
USB Port USB 2.0 port for compatible USB devices, such as digital cameras,
USB disks, and USB printers.
WAN/LAN1 Port WAN/LAN1 port for connecting to an Ethernet network through a
switch or a router.
LAN2 Port LAN2 port for connecting to a local Ethernet network through a
switch or a router.
System Fan System fan that exhausts heat from the unit.
Power Connector Connect the included power cords to this connector.
Reset Button
Resets the N2200XXX.
Pressing and holding the Reset button on the back for 5 seconds
will reset your network setting and password, and turn off Jumbo
Frame Support.
