To connect the 1U4200XXX/1U4600 to your network, follow the steps below:
1. Connect an Ethernet cable from your network to the WAN/LAN1 port on the
back panel of the 1U4200XXX/1U4600.
2. Connect the provided power cord into the universal power socket on the back
panel. Plug the other end of the cord into a surge protected socket. Press the
power supply switch to turn on the power supply.
3. Press the power button on the front panel to boot up the
1U4200XXX/1U4600.
NOTE
If you are installing the 1U4200XXXR/1U4600R, be sure to
connect both power cables. If you do not, the system will
assume one power supply has failed, and an alarm will sound.
