Thecus N5550 User Manual

191
The JBOD device will have a unique ID that ranges from 1 to 10. The disk no. lead
ID will indicate the different JBOD devices. The screen shot below show a JBOD
device with ID 4, so J4-6 is indicated under the JBOD device disk list with 6 slots.
Data Guard (Local Backup)
The Thecus product provides complete backup solution between Thecus NAS
systems as well as between folders of local systems. For remote data guard backup,
please refer to chapter 4, Data Guard (Remote backup).
Remote Data backup
Item
Description
Add
Add a new task.
Edit
Edit selected task.
Remove
Remove selected task.
Start
Click on start to start a scheduled scan task right away.
Stop
Stop the associated running task. Also can be used if a task
has been setup as real-time, clicking “Stop” can terminate
the running process. Simply click ‘Start” to re-start the
real-time operation.
Restore
Restore the associated task.
Log
Click to view the associated task process details.
Restore NAS Configuration
Click to restore the system configurations from a selected
destination to a source unit.
-From the Data Guard function list, select Add. The data backup setup wizard
appears as below, click on “Local Backup”:

Thecus N5550 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	ext3, ext4, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	5
Internal memory	2 GB
Internal memory type	DDR3
Processor family	Intel Atom®
Number of processors installed	1
Wi-Fi	No
Data link protocols	TCP/IP/AppleTalk
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports	1 x mic in 1 x line in 1 x audio out
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms	256-bit AES
Cables included	AC
FireWire 400	FireWire-interface with a data transmission speed of 400 Mbit/s (50MB/s). FireWire is a serial computer bus technology designed as replacement of SCSI and is based on the IEEE 1394 and 1394b standards.
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Bundled software	Acronis True Image Thecus Backup Utility
Display type	LCD
Product color	Black
Power supply unit (PSU) capacity	200 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Certification	CE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE

Weight and Dimensions

Depth	240 mm
Width	190 mm
Height	230 mm
