Thecus N5550 User Manual

72
compatible list. Therefore, the screen shown above is an example of a Thecus
N16000 with 3 on board GbE NIC and an additionally Intel PRO/1000 PT quad port
NIC, for a total of 7 NIC ports.
Network Configuration (Global parameter)
Item
Description
Host name
Host name that identifies the Thecus IP storage on the network.
Domain name
Specifies the domain name of Thecus IP storage.
WINS Server
To set a server name for NetBIOS computer.
DNS Mode
Select the DNS server is coming from DHCP server or manual input.
A total of 3 DNS servers can be input. If the DNS setting is chosen
from DHCP server, then it will refer to WAN/LAN1 port.
DNS Server 1,2,3
Domain Name Service (DNS) server IP address.
Network Configuration (NIC port)
Link speed
Display associated NIC port link speed.
Link status
Display associated NIC port link status.
MAC address
MAC address of the network interface.
Jumbo Frame Support
Enable or disable Jumbo Frame Support of associate interface on your
Thecus IP storage.
IPv4/IPv6
Click to enable IPv4/IPv6 for TCP/IP. The default is IPv4 enabled.
Mode
It can choose a static IP or Dynamic IP.
IP
IP address of associate NIC interface.
Netmask/Prefix Length
Input netmask for IPv4 and Prefix length for IPv6.
Gateway
Gateway for associate NIC.
Default gateway
It can be chosen from a drop down list of default gateway that’s been used
for the Thecus IP storage.
VLAN
Each NIC is capable of VLAN support. To enable VLAN, simply click the check box
and input the VLAN ID (VLAN ID can be any digital number). The system with the
same VLAN ID will become a Virtual LAN group to allow more specific
communication among members.
WARNING
Most faster Ethernet (10/100) Switches/Routers do not support Jumbo Frame and will not be
able to connect to your Thecus NAS after Jumbo Frame is turned on.
NOTE
• Only use Jumbo Frame settings when operating in a Gigabit environment where
all other clients have Jumbo Frame Setting enabled.
• Proper DNS setting is vital to networks services, such as SMTP and NTP.

Thecus N5550 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	ext3, ext4, XFS
Storage drive interface	Serial ATA
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	5
Internal memory	2 GB
Internal memory type	DDR3
Processor family	Intel Atom®
Number of processors installed	1
Wi-Fi	No
Data link protocols	TCP/IP/AppleTalk
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
I/O ports	1 x mic in 1 x line in 1 x audio out
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista/ 7 UNIX/Linux Mac OS X
Security algorithms	256-bit AES
Cables included	AC
FireWire 400	FireWire-interface with a data transmission speed of 400 Mbit/s (50MB/s). FireWire is a serial computer bus technology designed as replacement of SCSI and is based on the IEEE 1394 and 1394b standards.
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Bundled software	Acronis True Image Thecus Backup Utility
Display type	LCD
Product color	Black
Power supply unit (PSU) capacity	200 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Certification	CE/FCC/C-Tick/VCCI/BSMI VMware, Citrix, WEEE

Weight and Dimensions

Depth	240 mm
Width	190 mm
Height	230 mm
