Checking System Status
After making connections on the N8800SAS and powering up, check whether the
system status is normal or has trouble by observing indicators on the front panel
and hard disk trays.
System Status Normal
The system status is normal if:
1. The Power LED on the Front Panel glows green.
2. The HDD Power LED on each HDD tray glows blue (assuming all disks are
installed).
3. The default IP address of the WAN port is 192.168.1.100 on LCD.
System Trouble
The system has trouble if:
1. Disk Busy LED glows red.
If the system has trouble, please refer to Chapter 7: Troubleshooting.
There are no user serviceable parts inside the N8800SAS. Please contact
your distributor for service.
WARNING
17
