System Network
Use the System Network menu to make network configuration settings as well as
service support settings.
WAN Configuration
From the System Network menu, choose WAN, and the WAN Configuration
screen appears. This screen displays the network parameters of the WAN
connection. You may change any of these items and press Apply to confirm your
settings. See a description of each item in the following table:
WAN Configuration
Item Description
Host name Host name that identifies the N8800SAS on the network.
Domain name Specifies the domain name of the N8800SAS.
WINS Server To set a server name for NetBIOS computer.
MAC Address MAC address of the network interface.
Jumbo Frame Support Enable or disable Jumbo Frame Support of the WAN interface on your
N8800SAS.
IP Sharing Mode When enabled, PCs connected to the LAN port will be able to access the
WAN.
Link Aggregation Specifies whether WAN and LAN ports will be aggregated and act as one
port.
Load Balance: Ethernet traffic will flow alternative between two Ethernet
ports.
Failover: When one port fails, the other one will take over.
802.3ad: Linkage two Ethernet ports in parallel to increase throughput.
Set IP Address by:
Static / Dynamic
You can choose a static IP or Dynamic IP, and input your network
configuration.
IP IP address of the WAN interface.
Netmask Network mask, which is generally: 255.255.255.0
Gateway Default Gateway IP address.
39
