INSTALLATION INSTRUCTIONS
THIS APPLIANCE IS NOT INTENDED FOR USE BY
YOUNG CHILDREN OR INFIRM PERSONS WITHOUT
SUPERVISION. PLEASE ENSURE THAT YOUNG
CHILDREN ARE SUPERVISED TO ENSURE THAT THEY
DO NOT PLAY WITH THE APPLIANCE.
CONTROLLER MOUNTING
Find a suitable location to mount the control box.
Ideally, as with all pool equipment, it should be
installed out of direct weather and no closer than
3 metres from the water’s edge, at a minimum
600mm above ground. The power cable is 1.8m
long and should be plugged directly into a general
power outlet, not into an extension lead.
Mount the pump and sanitiser according to the
manufacturer’s instructions.
SANITISER CONNECTION
The sanitiser (Ioniser, Chlorinator, etc) can be
connected to any of the 240V sockets on either the
Master Controller or on one of the Expansion
Units. The sanitiser must be set to operate 24hrs
per day as the Pool+ Manager A2 controller will
control the number of hours per day the system
will operate. Refer to the sanitiser instructions for
24hr timer setup and dosing requirements.
Note: Both the Sanitiser and the Filtration pump
will need to be allocated sockets in 6.1 of the
Installer Menu.
POWER OUTPUT CONNECTIONS
The 240VAC Output Sockets are for equipment to
be controlled via the Pool+ Manager A2 controller.
Each socket can be assigned via the menu and/or
app.
The maximum combined load for both sockets on
the master controller, is 9.98 AMPS at 2395W.
HEATER CONTROL
Set the heaters temperature limit to maximum
(40°C). The heaters internal control will be
interrupted, to turn off heating. The heater
interlock cable connects to the green socket
marked INT which switches on (closes) the voltage
free NO/C relay contacts when the heater is to be
turned on. The heater end of the interlock cable
connects in series with the heater’s pressure/flow
or fireman’s switch. Contact the heater
manufacturer for the best location to connect to.
The heater interlock is for extra low-voltage (MAX
30V at 2Amps) switching only.
Note: If the heater’s flow or pressure switch circuit
is 240Vac, an external relay (KIT10) which can be
purchased separately, is to be connected by a
licensed electrician.
If the heat pump/gas heater is equipped with a
“Demand Heat” function, the heater interlock
cable will be connected into the socket labelled as
“Pump Call”. The controller will over-ride the filter
pump when flow is called for by the heat pump
which monitors the temperature within its own
defined run times. Connect the heater cable from
the controller output to the heater’s connection
point. Check with heater manufacturer for correct
interlocking procedure.
Note: If the heater’s flow or pressure switch circuit
is 240Vac, an external relay (KIT11) which can be
purchased separately, is to be connected by a
licensed electrician.
VALVES
The Pool+ Manager A2 has 4 valve actuator sockets
for the controlling of solar heating, water features,
pool/spa water flow, and In Floor cleaning.
Note: If wiring your own supplied valve then wire
as per the label on the base of the controller (Red,
Black then White) red and white are for direction
control and black is the common. Ensure the
switch on the valve actuator is in the ON position.
Refer the valve instructions for mounting
requirements, cam adjustments etc.
Maximum power for the VALVE output is 24VA.
SENSORS
Fix the mounting bracket to a solid structure via
screws and wall plugs kit provided, and slide the
controller on, locking into place. Adjust the
screws on the back of unit to ensure a snug fit.
To remove unit, lift and gently pull away from
mounting bracket.
