THERMACUT EX-TRAFIRE 75SD - Hand Torch Setup

EX-TRAFIRE
®
75SD
Operator Manual, Revision T-5 2-15
Hand torch setup
Ground Work lead Power lead Gas supply
Torch lead
P
view P
Torch lead Work lead
Workpiece
Work table
Gas hose (min� Ø8 mm)
min� 270 LPM
min� 6 bar
max� 10 bar
