THERMACUT EX-TRAFIRE 75SD - Machine Torch Setup

EX-TRAFIRE
®
75SD
Operator Manual, Revision T-52-16
Machine torch setup
Ground Work lead Power lead Gas supply
Torch lead
Machine
interface cable
P
view P
Torch lead Work lead
Workpiece
Work table
Gas hose (min� Ø8 mm)
min� 270 LPM
min� 6 bar
max� 10 bar
