TSBC Instruction Manual Page 45 of 48
Appendix A
Parameter Summary
Network
Relevant*
Parameter Range / Choices
Security
Level**
Page
Boiler Configuration Menu
Update Display Units Deg F / Deg C Basic 28
Yes Boiler Pump None / On Always / Purge / On Lead Supervisor
28
Update If Purge, set Pump Prepurge 0 to 600 seconds Supervisor
28
Update Postpurge Delta 0 to 20 F Supervisor
28
- Inlet Sensor Yes / No Supervisor
28
- Mixing Valve Yes / No Supervisor
28
Update Set Time/Date
hour : minute month / day / year
Basic
28
Update Fuel Limit Yes / No Factory
28
Update Spare Input Off / Sys Pump Feedback / Low Fire Supervisor
28
Update Spare Output Off / CAD / Sys Pump BU / Soft Alarm Supervisor
28
System Configuration Menu
Yes DHWP Off / Isolated Demand / Shared Demand Basic 29
Yes Remote control
No / Remote SP / Modbus SP /
Remote Mod / Modbus Mod Supervisor
29
- Remote 1 volts = 60 F to150 F Supervisor
29
- Remote 9 volts = 150 F to 230 F Supervisor
29
Yes Remote Sensor No / Display Only / Control
Supervisor 29
Yes System Pump Yes / No
Supervisor 29
Update LWC or CAD Yes / No
Supervisor 29
Update Alarm Message Low Water level
Supervisor 29
Setup Menu
Yes WWSD
Off / WWSD of Boiler / WWSD of Sys
Pump / Both Basic 30
Yes LL Start Trigger 50 to100% of Modulation Rate
Supervisor 30
Yes LL Stop Trigger 0 to 50% of Modulation Rate
Supervisor 30
Yes Boiler On Delay 0 to 900 seconds
Supervisor 30
Yes Boiler Off Delay 0 to 900 seconds
Supervisor 30
Yes %FR On Delay 1 to 30 minutes Factory
30
Yes %FR Off Delay 1 to 30 minutes Factory
30
Yes High Fire Limit 40 - 100 % Modulation Rate Supervisor
30
Yes Deg/Min Hold Off 1 - 10 Degrees / Minute Factory
30
Yes Cutback Setpoint 100 F - 240 F Factory
30
Yes Net Start Dwell 16 to 420 Seconds Factory 31
Yes Limit Fault Time 3 to 120 Seconds Factory
31
Yes Rotation Enable / Disable Basic
31
Yes Rotation After 8 to720 hours Basic
31
Yes Outdoor Sensor No / Display Only / Outdoor Reset Basic
32
Yes Outdoor Set Up 40 F to 100 F Basic
32
Yes Boiler Set Up 80 F to 180 F Basic
32
Yes Outdoor Design - 20 F to 50F Basic
32
Yes Boiler Design 80 F to 220 F Basic
32
Parameters identified by “Yes” under the “Network Relevant” column must be configured identically on all boilers.
Unexpected boiler behavior may result if these parameter values differ among boilers on the network. Once
communication is established between all boilers in a system, changes to parameters identified as “Yes” or
“Update” under the “Network Relevant” column at the keypad of any boiler will update that parameter in all boilers.
** To change your current security level, refer to page 42 Security Level operations.
