TSBC Instruction Manual Page 41 of 48
Trouble Shooting
Sensor Temperature vs. Resistance
Water Temperature Ohms of Water Temperature Ohms of Water Temperature Ohms of
°C °F Resistance °C °F Resistance °C °F Resistance
-22 -8 110,460 14 58 16,126 51 124 3,453
-21 -6 103,486 16 60 15,313 52 126 3,311
-20 -4 96,999 17 62 14,546 53 128 3,176
-19 -2 90,962 18 64 13,822 73 164 1,565
-18 0 85,340 19 66 13,139 74 166 1,508
-17 2 80,103 20 68 12,493 76 168 1,453
-16 4 75,222 21 70 11,884 77 170 1,401
-14 6 70,670 22 72 11,307 78 172 1,350
-13 8 66,424 23 74 10,762 79 174 1,302
-12 10 62,460 24 76 10,247 80 176 1,256
-11 12 58,759 26 78 9,760 81 178 1,212
-10 14 55,301 27 80 9,298 82 180 1,169
-9 16 52,069 28 82 8,862 83 182 1,129
-8 18 49,047 29 84 8,448 84 184 1,089
-7 20 46,220 30 86 8,056 86 186 1,052
-6 22 43,574 31 88 7,685 87 188 1,016
-4 24 41,097 32 90 7,333 88 190 981.2
-3 26 38,776 33 92 6,999 89 192 947.9
-2 28 36,601 34 94 6,682 90 194 915.9
-1 30 34,562 36 96 6,382 91 196 885.2
0 32 32,650 37 98 6,097 92 198 855.7
1 34 30,856 38 100 5,826 93 200 827.3
2 36 29,171 39 102 5,569 94 202 800.1
3 38 27,590 40 104 5,325 96 204 773.8
4 40 26,104 41 106 5,093 97 206 748.6
6 42 24,707 42 108 4,872 98 208 724.3
7 44 23,394 43 110 4,663 99 210 700.9
8 46 22,159 44 112 4,463 100 212 678.4
9 48 20,997 46 114 4,273 101 214 656.8
10 50 19,903 47 116 4,093 102 216 635.9
11 52 18,873 48 118 3,921 103 218 615.8
12 54 17,902 49 120 3,757 104 220 596.5
13 56 16,988 50 122 3,601
