Technical Spec
TY-142 FAN Spec
Dimension: L152mm x H140mm x W26.5mm
Weight: 175g
Rated Speed: 800RPM (PWM controlled)
Noise Level: 15dBA
Air Flow: 45.32CFM
Connector: 4 Pin (PWM Fan connector)
Heatsink Specications:
Dimension: L140mm x W102mm x H162mm
Weight: 710g (Heatsink only)
Heat pipes: 6mm heatpipe*6 units
Fin: T = 0.4 mm ; Gap = 3.1 mm
Fin Pcs: 31 pcs
Copper Base: C1100 Pure copper nickel plated
Motherboard to Fin: 45 + 8 = 53 mm
