Available pressure - Rad system
Recommended min. ow rate
Total 300L Total EQ Compact
External available pressure with internal circulation pump for Athena.
When calculating the available pressure for Total EQ, the internal pressure loss was taken into account due to its two circulation pumps,
where one works towards the rad system. For Total 300L and Compact, the total pressure in the heating system was considered.
Indoor unit
Unit Min Max
Total 300L l/min 18 34
Total EQ l/min 18 39
Compact l/min 18 32
Technical description Athena
Thermia AB AWAT01TD0102
15
