3 Technical data Athena 14 400V H/HC
3.1 Technical data Athena 14 400V H/HC
Athena 14 outdoor units Units Athena 14 400V H Athena 14 400V HC
Heating capacity
1
kW 7,85-13,98
Refrigerant Type R410A
Amount
2
kg 4,70 5,50
CO2 equivalent tCO2e 9,810 11,480
Design pressure bar(g)
Compressor Type Scroll
Oil POE
Electrical data, 400V ~3N 50Hz Mains power supply V 400~3N
Max working power, compressor kW 5,5
Immersion heater
3
kW 8,8
Fuse separate supply
3
A 16
Max current, compressor only A 7,9
Max current, immersion heater only A 14
Performance SCOP, floor heating (35°C) - cold climate 4,2 4,25
SCOP, radiator heating (55°C) - cold climate 3,22 3,25
SCOP, floor heating (35°C) - average climate 4,7 4,87
SCOP, radiator heating (55°C) - average climate 3,65 3,74
A7/W35 / A7/W65 (max. power output) kW 10,8/13,98
A-7/W35 / A-7/W65 (max. power output) kW 10,14/11,06
COP (A7W35) 5,09
Energy class - system Floor heating (35°C) A+++
Radiator heating (55°C) A++
Energy class - product Floor heating (35°C) A+++
Radiator heating (55°C) A++
Max temperature Heating circuit °C 65
Operating temperature range (outdoors) Heating/hot water °C -20~+37
Cooling °C +15~+37
Sound power level Normal operation - EN12102 - A7/W55 dB(A) 55
Max dB(A) 66
Sound pressure level - open field 1/5/10m dB(A) 48/32/28
Weight kg 176,5 188
Dimensions (WxDxH) mm 1495x593x1045
1) Min. output corresponds to part-load at A7/W35 and max. output to full compressor speed at A7/W65
2) The refrigerant circuit is hermetically sealed and contains refrigerants covered by the F-gas regulation. The GWP for R410A according to EC 517/2014 is 2088, corresponding to 11,48 tCO2e for
Athena HC and 9,81 tCO2e for Athena H
3) The immersion heater located in the outdoor unit isn't allowed to run at the same time as the compressor, only allowed to run at low outdoor temperatures when the compressor is OFF
Technical description Athena
Thermia AB AWAT01TD0102
