Engine Maintenance

Fuel Solenoid Diagnostic and

Replacement

See the Interface Board diagnostic procedures in

the Microprocessor Controller Diagnosis Manual.

BELT TENSIONS

Correct belt tension is critical for proper unit

operation. Belts that are too loose will slip, squeal

or whip causing excessive vibration levels and

poor unit performance. Belts that are too tight will

cause excess vibration along with premature belt

and bearing failures.

NOTE: DO NOT attempt to remove or install

belts without adjustments. Belts that are installed

by prying will fail prematurely due to internal

cord damage.

1. Throttle Lever 6. Eye Bolt

2. Fuel Solenoid 7. Boot

3. Low Speed Adjustment Screw 8. Throttle Solenoid

4. Rod 9. Ball Joint

5. Clip

Figure 40: Integral Fuel Solenoid Components
