C-Link Protocol Commands
Datalogging
Thermo Fisher Scientific Model 48i Instruction Manual B-19
diag volt mib
This command reports the diagnostic voltage measurements on the
measurement interface board. The sequence of voltages is: Positive 24,
positive 15, negative 15, positive 5, positive 3.3, positive 18 IR, positive 18
MOT, and VBIAS. Each voltage value is separated by a space.
Send: diag volt mib
Receive: diag volt mib 24.1 14.9 -14.9 4.9 3.2 17.9 17.9
diag volt iob
This command reports the diagnostic voltage measurements on the I/O
expansion board. The sequence of voltages is: Positive 24, positive 5,
positive 3.3, and negative 3.3. Each voltage value is separated by a space.
Send: diag volt iob
Receive: diag volt iob 24.1 4.9 3.2 -3.2
version
This command reports the version of all the firmware components. The
example that follows shows a list of firmware components that were
displayed by issuing the version command. The components displayed will
vary depending on the configuration of the instrument.
Send: version
Receive: version
Program = 01.05.79.225
Library = 01.01.60.167
Kernel = 2.4.24-uc0-003-Thermo
Board = 81, File = /usr/application.hex
Board App = 11.3.100 Bl 4.0.97
File App = 11.3.100 Bl 4.0.97
Board = 84, File = /usr/application.hex
Board App = 11.3.100 Bl 4.0.97
File App = 11.3.100 Bl 4.0.97
Arc Bl = 170711
clr records
This command will clear all lrecs and srecs that have been saved.
Send: clr records
Receive: clr records ok
set clr lrecs
set clr srecs
These commands will clear only the lrecs or only the srecs that have been
saved. The following example clears srecs.
