Thermo Scientific ModulyoD - Figure 4- Refrigeration Circuit Diagram

7
Figure 3 – INSIDE MODULYOD
3
2
4
5
7
1
6
1. Compressor
2. Thermo Expansion Valve
3. Suction-line Accumulator
4. Filter Dryer
5. Liquid Receiver
6. Fan
7. Condenser Coil
Figure 4 – REFRIGERATION CIRCUIT DIAGRAM
