MULTISKAN RC and MS SERVICE MANUAL
11.
Switch the instrument ON.
12. Measure and adjust voltage on the
lamp
connector to 6.7
...
6.9 V using
trimmer R39. See Figure
8-2.
13. Switch the instrument OFF and
disconnect from the mains. Reinstall
the track and the measuring assembly
cover.
Figure 8-1
Track
screws
Figure
8-2
Power
supply
Document Release Section Page
Labsysterns
351/352- 100-X 1
.O
8
4
