Outputs
On the top of the boiler, below cover lidare there are conectors for :
 Power supply 230 V, 50 Hz
 Circulating boiler pumps P1, P2, P3
 Motorized mixing/diverting valve,
 Sensor for engine mixing valve
 Storage tank sensors
 Room thermostat
When installaling, it is necessary to remove the top cover and to pull the connection
cables through the trench which is located between the tank and the boiler body.
All other devices and motors required for operation are already connected.
The connection of the boiler may only be carried out by an authorized
servicer with the required certificate .
