Info display
When the boiler is connected to the power supply, the status and temperature information is
displayed on the screen:
- TEMPERATURE KOJE OČITAVAJU OSJETNICI
TBO – BOILER TEMPERATURE
TOUT – RETURN LINE TEMPERATURE
TBC – TEMPERATURE ON THE OUTPUT OF BURNING CHAMBER
- BOILER STATUS:
Boiler :
- OFF ,
- ON / Work ,
- Extinguishing
- Pause
Pressing the button „up“ ypu can choose info for other functions:
FAN – rada ventilatora dimnih plinova (Percentage)
AUG – rada dozatora (u procentima)
GRATE - CLOSE - OPEN
POWER - Snagu rada (u procentima)
Pressing the button „dowm“, you can see the instaled software version and the status of activted
heating cicuits (pump work) as well as signal and WLAN modul status.
