Thetford Cassette C2 User Manual

21322 Float arm
2. Porta Potti
Note : If the float retainer is still in the waste tank (float arm has fallen off), the new float arm can not be
assembled. Float retainer has to be taken out first. This can be done with a small flat screwdriver.
As the waste tank is welded, this can only be done through the hole in the middle.
Inside view to take the
float retainer out.
Place screwdriver
between rib and float
retainer and lift it up.
A.
Float arm
Float retainer
B.
For placing the new
float arm, open the
blade and go with
your hand in the
waste tank.
Magnet always has to
point to the outside of
the waste tank.
Inside view
waste tank.
Press the
float retainer
in.
C.
Leaflet no. 21774/052001
Place where float arm
has to be assembled
Position float arm,
view from the outside.
Magnet pointed
to the outside
3

Thetford Cassette C2 Specifications

General

Waste tank capacity	17 liters
Level indicator waste tank	Yes
Toilet type	Cassette toilet
Seat rotation	No
Material	Plastic
Battery Operated	No
Flush water tank capacity	15 liters
Flush system	Manual
Compatible Chemicals	Thetford Aqua Kem
