5. Open the latches on both sides of the memory slot at the same time 1 , and then remove the memory
module
2 .
Note: A Mylar film might cover the memory module. To access the memory module, open the film first.
6. Install the memory module by doing the following:
a. Place the notched end of the new memory module toward the contact edge side of the memory slot.
Then insert the new memory module into the memory slot at an angle of about 20 degrees
1 .
b. Pivot the memory module downward until it snaps into place
2 . Ensure that the memory module is
firmly installed in the memory slot and cannot be moved easily.
Note: If your computer is installed with only one memory module, ensure that the memory module is
installed in the memory slot next to the thermal fan assembly.
7. Reinstall the base cover assembly.
Chapter 9. Replacing devices 107
