5. Place the notched end of the new memory module toward the contact edge side of the memory slot.
Then insert the memory module into the slot at an angle of about 20 degrees
1 . Pivot the memory
module downward until it snaps into place
2 . Ensure that the memory module is firmly installed in the
slot and cannot be moved easily.
Attention: Do not touch the contact edge of the memory module. Otherwise the memory module might
get damaged.
Note: If you install only one memory module, install it into the bottom slot.
6. Reinstall the removable battery. See “Replacing the removable battery ” on page 113.
7. Reinstall the bottom cover. See “Replacing the bottom cover” on page 116.
8. Turn the computer over again. Connect the ac power adapter and all cables.
Replacing the coin-cell battery
Before you start, print these instructions.
124
P50 User Guide
