Chapter7.Locations
Thischapterintroducesthelocationsofthehardwarecomponentsonyourcomputer.
Locatingcomputercontrols,connectors,andindicators
Thistopicintroducesthelocationsofthecomputercontrols,connectors,andindicators.
Frontview
1
2
1
3
455678
9
10
11
12
13
1Microphones
2Camera
3Ambientlightsensor(forWindows8.1only)4High-DefinitionMultimediaInterface(HDMI™)
connector
5USB3.0connectors6Screen-rotation-lockbutton
7Volume-controlbuttons8Powerbutton
9System-statusindicator
10ThinkPadtrackpad
11TrackPoint
®
pointingstick
12WindowsStartscreencontrol
13Multi-touchscreen
©CopyrightLenovo2014
