ThinkPad Yoga 14 - 1130 Thinkpad-Logo-LED Card

3
3
Wheninstalling:Ensurethattheconnectorisattachedfirmlyandthecablesareroutedasshowninthe
followingillustration.
1130ThinkPad-logo-LEDcard
Foraccess,removetheseFRUsinorder:
•“1010Lenovo-OneLink-connectorcover”onpage60
•“1030Basecoverassembly”onpage63
•“1050Internalstoragedriveandthestoragedriveconnector”onpage66
RemovalstepsoftheThinkPad-logo-LEDcard
1
2
3
3
Wheninstalling:Ensurethattheconnectorisattachedfirmly.
74HardwareMaintenanceManual
