ThinkPad Yoga 14 - Display Assembly and Related Component Replacement

•“1030Basecoverassembly”onpage63
•“1040Batterypack”onpage65
•“1050Internalstoragedriveandthestoragedriveconnector”onpage66
•“1060Memorymodule”onpage67
•“1070WirelessLANcard”onpage68
•“1080Coin-cellbattery”onpage69
•“1090ButtonI/Ocard”onpage69
•“1100Audio/USB/OneLink/acpowercard”onpage70
•“1110M.2solid-statedrive”onpage72
•“1130ThinkPad-logo-LEDcard”onpage74
•“1140Mediacardreader”onpage75
•“1120Speakerassembly”onpage73
•“1150Systemboard”onpage75
•“1160Thermalfan”onpage77
RemovalstepsoftheLCDunit
1
1
1
1
StepScrew(quantity)Color
Torque
1
M2.5×3.5mm,flat-head,nylon-coated(4)Silver
0.2.94Nm
(3kgf-cm)
Chapter9.RemovingorreplacingaFRU79
