1070WirelessLANcard
Foraccess,removethisFRU:
•“1030Basecoverassembly”onpage63
RemovalstepsofthewirelessLANcard
2
1
1
StepScrew(quantity)Color
Torque
2
M2×3mm,flat-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
Wheninstalling:
PlugthegraycableintotheconnectorlabeledMAINor1onthecard;andplugtheblackcableintothe
connectorlabeledAUXor2onthecard.
68HardwareMaintenanceManual
