1 Signal
2 Ground, shielding
1 Signal (left)
2 Signal (right)
3 Ground
1 Signal (left)
2 Signal (right)
3 Ground, shielding
1/4" TS phone plug (mono,
unbalanced)
1/4" TRS phone plug (stereo,
unbalanced)
Three-pole 1/8" mini phone jack
(stereo, unbalanced)
Plug and pin assignments
56
