6. Activate the next pad or press [ENTER] to jump to the ‘Cross Talk’parameter.
When several pads are mounted on one tripod, vibrations may be transferred to other pads
and, thus, unwanted sounds are triggered when striking a trigger. This crosstalk can be pre‐
vented by the temporary suppression of the trigger signal.
1. Press the [KIT] button to change to the kit mode, followed by the [SETUP] button.
2. Repeatedly press the [ENTER] button or turn the rotary control [–] / [+] until the menu
item ‘Advanced’ appears in the display.
3. Press [SETUP] for confirmation to open the setup menu.
ð
Use the rotary control [–] / [+] to change to the fourth parameter ‘Cross Talk’.
4. Activate the desired pad using the pad selection buttons or by striking it.
ð
The symbol of the pad flashes in the display.
5. Use the rotary control [–] / [+] to adjust the signal suppression time to the desired value
in a range from 0 to 100.
Crosstalk
Operation
e-drum modul
44
