3 Assembly
Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specified sequence. The
final positions of the components are shown in the illustration below.
10 Tom pad 1 (8"), tom pad 2 (8")
11 Tom pad 3 (10"), tom pad 4 (10")
12 Snare pad
13 Hi-hat controller
16 Hi-hat pad
17 Crash 1, crash 2
18 Ride
19 e-drum module Millenium MPS-850
20 Hi-hat stand with pedal
21 Bass drum pad pedal
23 Bass drum pad
Assembly
e-drum set
8
