PHANTOM power switch and indicator (3)
Pressing this switch will apply +15 V phantom power to the XLR sockets. This voltage is
needed to supply condenser microphones. If you connect devices to the XLR sockets, that do
not require phantom power, make sure phantom power is turned off. Otherwise the device
may be damaged.
With phantom power activated, the PHANTOM indicator lights up, otherwise the LED is off.
DSP/FX AUX POST control (4)
This potentiometer is "post fader" configured and controls the "FX SEND" level. Thus, the
signal is affected by the channel fader. You can use the AUX1 signal to feed an external effect
processor.
LEVEL control (5)
Use this fader to set the desired volume of the respective channel from — ¥ to +10 dB.
3 band equalizer
Channels 1 - 8 offer a 3 band EQ, that provides a vast range for frequency correction.
Control elements
powermixer
16
