Balanced wired 1/4" TRS jack:
1 (Tip) Positive signal (+)
2 (Ring) Negative signal (–)
3 (Sleeve) Ground, shielding
3.2 Tips on speaker positioning
We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐
ence unobstructedly. Often tripod mounting is a good way to maximise dispersion and range.
Always use high grade cable to connect your equipment. Otherwise you won't reach max‐
imum sound quality.
For optimum results both impedance and power handling of the speakers must match the
requirements of the amplifier. Always follow the technical specifications of the speakers! The
overall impedance of the connected loudspeakers must not deceed the minimum output
impedance of the amp. The power handling of the speakers should be above the amp's output
power.
Installation
PM800
13
