4 Control elements
Front panel
SG/PEAK LED (1)
This LED lights up in green when a signal is present in the LINE/MIC input. When the signal
strength comes close to clipping, the LED turns red.
Mono input channels (2)
You can connect balanced, low impedance microphones or a low level signal to the XLR
socket. Use the 1/4" TRS (LINE IN) socket to connect instruments with line level outputs like
synthesizers, drum modules, preamps or the like.
NOTE: Never connect an unbalanced microphone to the XLR socket. Otherwise both the mic
and the mixer may be damaged.
Control elements
PM800
15
