thomann PM800 - 5 Technical Specifications

5 Technical specifications
Input channels Microphone inputs electronically balanced, discrete inputs
Frequency response
20 Hz to 20 kHz, ± 3 dB
Gain 50 dB
Line inputs electronically balanced
Frequency response
20 Hz to 20 kHz, ± 3 dB
Gain 20 dB
Impedance Microphone inputs 1.5 kohm
All other inputs 10 kohm or above
Tape out 1 kohm
All other outputs 120 ohm
Equalization Treble
± 15 dB @ 12 kHz
Mid range
± 12 dB @ 2.5 kHz
Technical specifications
PM800
25
