3 Installation
Unpack and check carefully there is no transportation damage before using the unit.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
3.1 Pin assignment
You can use XLR and phone jack connectors with either balanced or unbalanced wiring.
