REAR PANEL
OUTPUTS (33)
Connect your speakers to these output sockets (SPK and 1/4" sockets). The minimum output
impedance is 4 ohm.
AC INLET (34)
Connect the mains cable supplied here, to supply operating voltage to your powermixer.
VOLTAGE SELECTOR (35)
Use this switch to adjust the unit to the operating voltage available. When using the device
in Germany, this switch must be in "220 - 240 V" position. Otherwise the unit will be dam‐
aged and you're facing risk of electric shock.
Vents (36)
These are the ventilation openings used for heat dissipation and cooling. They must never be
obstructed during operation. Otherwise the unit may be damaged and you're facing risk of
fire.
Control elements
powermixer
24
