Drawings and descriptions explain the pin assignment of 1/4" connectors.
Unbalanced wired 1/4" TS jack:
1 Signal
2 Ground, shielding
Unbalanced wired 1/4" TRS jack:
1 Signal
2 Ground, shielding
1/4" connectors for signal in and
outputs
