37 [MIDI OUT]
The device sends MIDI data via the "MIDI OUT" socket.
38 [MIDI THR]
The "MIDI THRU" socket will forward the incoming MIDI data to the next MIDI device.
39 [AUDIO IN ]
You can connect audio line signals (0,1 V ~ 1 V
pp
) to this RCA socket to be used for the sound-controlled mode. When
this switch socket is used, the built-in microphone is deactivated.
40 [MIC]
Built-in microphone
Connections and operating elements
DMX controller
32
