Thomas 135 User Manual

3-11
3
AXLE ASSEMBLY 3.6
C1172
12
11
10
9
8
7
6
5
5
4
4
3
2
2
1
Axle Assembly T - 135 S
1 Axle 7 Wheel Stud
2 Key 8 Wheel Nut
3 Seal 9 Axle Sprocket
4 Bearing 10 Washer
5 Race 11 Castle Nut
6 Axle “Tower” 12 Cotter Pin
