Thomas 135 - Page 25

1
Disassembly 1300/135
GEAR PUMP 1.2
1. Front Plate Assembly 9. Shaft Seal
2. Back Plate 10. Washer
3. Body Assembly 11. Cap Screw
4. Drive Gear 12. Back up Gasket
5. Idler Gear 13. Seal
6. Plug 14. Key for Straight Shaft Models
7. Wear Plate 15. Washer
8. O - Ring Seal 16. Retaining Ring (optional)
1-15
2
3
4
1
8
5
7
8
9
10
13
12
11
15
14
16
6
