3. 6 AUXILIARY HYDRAULICS
To operate an attachment such as a grapple fork the Left
Hand Control Lever will be used. Push right of neutral on
the Auxiliary Hydraulic Control Switch to open the
grapple (Fig. 3.6J).
To close the grapple (Fig. 3.6K), push left of neutral on the
Auxiliary Hydraulic Control Switch, or push down on the
toe of the auxiliary pedal if so equipped. The lift arm and
bucket pedals can be used to raise and tilt the grapple as
with a bucket.
To operate an attachment which requires a constant flow of
oil, a toggle switch on the L.H. instrument panel (Fig.
3.6L) should be placed in the “ON” position.
When the auxiliary circuit is not in use switch to the
“OFF” position. Otherwise starting the loader may be
difficult or impossible and damage to the starter may
occur.
Return the auxiliary
control to neutral when
not in use otherwise
starting may be
impossible and damage
to the starter may occur.
IMPORTANT
3. OPERATION
Fig. 3.6J
Fig. 3.6K
To avoid personal injury,
lower the lift arms, shut off
the engine, raise the seat bar
and cycle the hydraulics to
ensure they are locked. Then,
unlatch the seat belt and exit
the loader. Do not enter or
exit with the engine running
unless as specified in this
manual or under specific
service and backhoe
operating procedures.
WARNING
C723
C724
C3022
C3022
Fig. 3.6L
C3793
Toggle Switch
