41
2. Oil Level Check
Check the oil before engine start up. If the engine has been
running let it cool for at least 5 minutes.
To check the oil level, stop the engine with the loader on
level ground, open the rear door and remove the dipstick
(Fig. 4.8A).
Keep the oil level between the full and low mark on the
dipstick. Do not fill above the full mark.
3. Engine Oil and Filter Replacement
Operate the engine until warm, approximately 5 minutes.
Stop the engine. Remove the oil drain plug located at the
bottom of the oil pan. Remove the oil filter (Fig. 4.8B).
Clean the filter housing surface. Put clean oil on the seal of
the new filter and install the filter hand tight.
Replace the oil drain plug. Remove the filler cap and add
10W30 API classification CF engine oil. Start the engine
and run for 5 minutes. Stop the engine and check for leaks
at the filter. Recheck the oil level and add oil until the level
is at the top mark on the dipstick.
WARNING
To avoid personal injury:
Stop, Cool and Clean the
engine of flammable
materials before
servicing. Never service
or adjust machine with
engine running.
4. MAINTENANCE
C3415
Fig. 4.8A
Dipstick
Location
C828
Fig. 4.8B
Engine Oil
Filter
Thomas recommends
that you abide by all
applicable enviromental
regulations when
disposing of oil.
IMPORTANT
4. 8 ENGINE MAINTENANCE
1. Engine Specifications 153 135TA/137
Make............................................................................................Kubota............................................Kubota
Model...........................................................................................V2203E..........................................V1903E
No. of Cyls ..................................................................................4......................................................4
Horsepower (Gross) ....................................................................49....................................................42
Power (ISO9249 Net Power) ......................................................34.3 kW...........................................29kW
Power CE (ISO9249 Net Power) ................................................33.8 kW...........................................28.9kW
High Idle............................................................................. ........2800................................................2800
High Idle CE ...............................................................................2600................................................2600
Max. Torque.................................................................115 ft.lbs. (15.9kg/m@1600)............89.1 ft.lbs. (12.3 kg/m @ 1600)
Displacement ...................................................................... 134 in.
3
(2197 c.c.)..........................113.5 in.
3
(1861 c.c.)
Engine Oil ...................................................................................8.5 qts. (8 L)...................................8.5 qts. (8 L)
Firing Order.................................................................................1 - 3 - 4 - 2......................................1 - 3 - 4 - 2
Alternator.....................................................................................40 A.................................................40 A
Oil Check.....................................................................................Daily................................................Daily
Oil Change...................................................................................150 hrs............................................150 hrs.
Filter Change ...............................................................................150 hrs............................................150 hrs.
