3. OPERATION
3.11 ACCUMULATOR
The accumulator (fig. 3.11A) stores system pressure until
it is required to activate the electric auxiliary. The key
must be placed in the “On” position to operate the electric
auxiliary (engine not running).
The electric auxiliary and stored system pressure can be
used to activate the spools. This decreases the hydraulic
pressure from the male/female couplers located on the lift
arms. This is accomplished by cycling the momentary
switch on the L.H. control a couple of times (fig. 3.11B).
Once this pressure is decreased the operator can
remove/replace the quick attach accessories easily.
C3901
Fig. 3.11A
Accumulator
C3915
Fig. 3.11B
Momentary
Switch
ROPS SIDE
SEAT SIDE
27
