THOMSON STREAMING BOX PLUS 270 - Technical Specifications; Audio and Video; System and Memory; Ports

23
How do I use Google Assistant?
Press the Google Assistant button on the remote control of the Streaming Box Plus 270.
You can search for any content. All content related to your question will be displayed in
the list.
How can I find out that a new software version
available for my streaming device?
Software updates for the Streaming Box Plus 270 are automatic. When updates are
available for installed applications or the operating system, notification icons will
appear next to the Settings icon in the top right corner of your screen. Click the OK
button on your remote control to read them.
Can I also use my Streaming Box Plus 270 as a
an IPTV box?
Yes, the Streaming Box Plus 270 can be used for IPTV. To do this, you must
download a favourite IPTV application.
17 Technical Specifications
17.1 Audio and video
Screen resolution: 4K Ultra HD
Video resolution: 4Kx2K @ 60 fps, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
Audio decoding: Dolby Digital, Dolby Digital Plus, Dolby Atmos MS12
17.2 System and Memory
Operating system: Google TV - ATV12
Chipset: Amlogic S905X4-J
CPU: ARM Quad 64-bit Cortex-A55 GPU: ARM Mali-G31 MP2
SDRAM: LPDDR4 3GB
Memory: eMMC 32 GB
17.3 Ports
HDMI 2.1 (TMDS)
USB 3.0 connection (5 V, max. 900 mA) Ethernet (RJ-45) 10/100M
17.4 Speaker and Microphone
Speaker: 1 x 3 W, 4 Ohm, mono speaker/1.5" Full frequency/FRR: F0~20 kHz
Microphone: 2xMICs
17.5 Wireless connectivity
Integrated Wi-Fi: 802.11 b/g/n/a/ac/ax, 2.4 GHz /5 GHz 2T2R
Bluetooth: 5.2
Bluetooth: 2400 MHz~2483.5 MHz (79 channels)
2.4G WIFI: CH1~CH14 2400MHz-2483.5MHz
5G WIFI: CH36~CH48 5150MHz-
5250MHz CH52~CH64
5250MHz-5350MHz
CH100~CH140 5470MHz-
5725MHz CH149~CH165
5725MHz-5850MHz
Effective isotropic RF radiated power, EIRP:
2.4G WIFI: EIRP < 20 dBm
