TS 840 TRANSFER SWITCH
PM057 REV 8 10/01/25 26 Thomson Technology
13. CABLE TERMINAL INFORMATION
TERMINAL RATING
CONNECTION TIGHTNESS
(In-lbs)
BASIC MODEL
QTY
PER PHASE
RANGE
TERMINAL
MOUNTING
SCREW
CABLE
CLAMP
TS 84xA-0100
1 #14-1/0
120 50
TS 84xA-0150
1 #2–4/0
120 120
TS 84xA-0200 1 #6–350MCM 150 275
TS 84xA-0250 1 #6–350MCM 150 275
TS 84xA-0400
1
2 2/0–500MCM 72 275
TS 84xA-0600
1
2 2/0–500MCM 72 275
TS 84xA-0800
1
3 2/0–500MCM 110 375
1. Optional terminal ratings are available in some models – Consult Thomson Technology.
2. For other model types not shown, contact Thomson Technology for further information.
14. REQUIREMENTS FOR UPSTREAM CIRCUIT PROTECTIVE DEVICES
14.1. WITHSTAND CURRENT RATINGS (ALL MODELS WITHOUT INTEGRAL
OVERCURRENT PROTECTION OPTION)
WITHSTAND CURRENT RATING AMPS (RMS)
1
With Upstream Circuit Breaker
Protection
With Upstream Fuse
Protection
BASIC MODEL
MAX.
VOLTAGE
RATED
CURRENT
(A) @240V
@ Up to
240V Fuse Type
TS 84xA-0100 240 100 65,000 100,000 T, J
TS 84xA-0150 240 150 65,000 100,000 T, J
TS 84xA-0200 240 200 65,000 N/A T, J
TS 84xA-0250 240 250 65,000 100,000 T, J
TS 84xA-0400 240 400 65,000 100,000 T, J
TS 84xA-0600 240 600 65,000 100,000 T, J
TS 84xA-0800 240 800 65,000 100,000 Consult Factory
1. Standard ratings only are shown. Consult Thomson Technology for versions with higher withstand current ratings.
2. For other model types not shown, contact Thomson Technology for further information.
Fuse ratings shown are maximum allowable to permit use of the transfer switch in application with
available fault current not exceeding that shown. Consideration must be given to fuse sizing when
fuses also provide overload protection.
