7. Positioning of Range
You may install a non-combustible material, such as tile, on the rear wall above the range and
up the vent hood.
It is not necessary to install non-combustible materials behind the range below the counter top
height.
DO NOT INSTALL CLOSER THAN 12 MM FROM ANY ADJACENT SURFACE.
The minimum distance from the side of the range above the counter top to combustible
sidewalls must be at least 18 inches.
A is allowed
distance between
bottom of cabinet
and stove.
bottom
