33
Further Tonearm Adjustments
The tonearm headshell allows an overhang adjustment
of ± 2,5 mm to be made. To adjust overhang, loosen the
screw holding the headshell and move the headshell as
required. ➔ Fig. 13
A screw at the rear of the tonearm allows a further over-
hang adjustment of ±3 mm as well as an azimuth ad-
justment of ±5°. The screw is recessed into the top of
the bearing housing and can be loosened with a 2-mm
hex key. ➔ Fig. 14
The vertical tracking angle (VTA) can be adjusted by
raising or lowering the tonearm. ➔ Page 34
Take care not to over-tighten the screws after making
adjustments.
Fig. 13
Fig. 14
